House plan 2 bedroom and 1 bedroom block of flats

Overview of the 2-Bedroom & 1-Bedroom Block of Flats House Plan

The uploaded ground-floor plan shows a modern residential block made up of four separate apartments—two units of 2-bedroom semi-detached flats and two units of 1-bedroom semi-detached flats combined within a single building footprint. The design follows a symmetrical arrangement where each pair of apartments mirrors the other, making the structure economical and suitable for rental or family housing. Every unit is accessed through a small veranda, which leads directly into the main lounge area, creating a welcoming transition from the exterior into the living space.

In the 2-bedroom apartments, the lounge connects smoothly to the dining space and kitchen, forming an open living zone. A short lobby corridor links the private areas, which include two bedrooms fitted with wardrobes and a toilet/bathroom. The layout provides good privacy between rooms while still maintaining easy movement within the apartment. Multiple windows labeled on the plan (W1, W2, W3) and the verandas on opposite sides encourage cross-ventilation and natural lighting, making the units comfortable for warm climates.

The 1-bedroom apartments follow a similar but more compact arrangement. Each unit contains a lounge, dining, kitchen, one bedroom with wardrobe, and a toilet, all connected through a small lobby. The repetition of service spaces such as kitchens and toilets across all four flats shows that the plan was designed with cost-effective construction in mind, allowing plumbing and structural walls to be shared between adjoining units.

Based on the dimensions written on the drawing in meters, the total ground-floor footprint measures approximately 17.45 m in width and 16.05 m in length, which converts to about 57.3 ft by 52.7 ft. When compared with a plot size of 50 by 100 ft, the building width is wider than the available 50 ft frontage. This means the plan is not fully suitable for a 50×100 ft plot without modifications, because there would be little or no space left for setbacks, parking, drainage, and external circulation required by most building regulations.

Overall, this is a solid modern block-of-flats design that efficiently accommodates four households with clear functional zoning and good ventilation. With a slight reduction in the overall width or a redesign of the verandas and wall thicknesses, the concept could be adapted to fit a standard 50×100 ft plot while still retaining its key features.
